Designing before building¶

An engineer updates the local credentials on every device in the network. By hand. The change is applied correctly to most devices, but the engineer introduced a typo to one. From that moment, the organization's record of its own credentials is wrong. The password manager says one thing and the device holds another, and nothing anywhere will notice the difference. Not monitoring, which is watching interfaces. Not the configuration backup, which faithfully stores the new value as though it were intended. Not the operations staff, whose logins are authenticated against a TACACS service. The gap opens silently and stays open — through the next audit, through the handover when that engineer leaves, until the night something goes wrong and the device cannot reach the TACACS server. The lockout remains invisible until the network is down, logins require local credentials, and it's too late to fix it without going onsite.

This series builds a system that closes that gap automatically: it keeps a record of what each device's secrets are supposed to be, notices when a device changes, checks the configured secrets against the record, and puts the right value back when they disagree. The eight articles that follow this one each include a working archive you can download and run against real router software on your laptop.

The interesting part is not the automation. It is that the system is deliberately built as several small services rather than one program — a microservice architecture applied to network automation — and this article is the design.

It is also the article that tells you where that design was wrong. Not as an afterthought at the end: three things in this document turned out to be mistakes, and all but one of them was corrected by measuring something rather than by thinking harder. You will meet each correction in the article that found it.

What are we doing here?¶

This series of articles builds Quelaag, a system for identifying credential drift on network devices, and automatically correcting that drift. After reading the series you will understand:

• Benefits and drawbacks of a microservice architecture
• The importance of well-defined boundaries
• The value of measuring while building
• Synchronous vs. asynchronous APIs

The author also employed AI assistance during this project, with spec-kit and Claude Code, specifically. All of the code is Claude's. I deliberately left its mistakes uncorrected. The article prose is either mine, or heavily edited.

What are we not doing here?¶

Crucially, we are not building a production-ready system. To make the code accessible to network engineers, not just developers, we minimize defensive code. This prevents the business logic from being obscured by exception handling, logging, input validation, and the like. We don't avoid it entirely, but keep it to a minimum. Lastly, the system lacks many features that would be required in production: support for external secret stores, multiple hardware platforms, and triggering on password changes, among others.

The system in a nutshell¶

Quelaag is six components. Three are deployable services; the other three are not, and which is which turns out to be the first real design decision.

flowchart LR
    subgraph lab["Network lab (external target)"]
        device["Lab devices"]
    end

    receiver["Syslog receiver"]
    engine["Assurance engine"]

    subgraph owned["Verification service's boundary"]
        service["Verification service"]
        library["Verification library"]
        vault["Secrets vault"]
    end

    device -- "config-change syslog" --> receiver
    receiver -- "assurance request" --> engine
    engine -- "verify hash / request correct hash" --> service
    engine -- "fetch configuration" --> device
    engine -- "apply correction" --> device
    service -- "generate / verify" --> library
    service -- "read / write secrets" --> vault

    classDef svc stroke-width:3px
    class receiver,engine,service svc

The six components, with one responsibility each:

• The network lab stands in for production — emulated devices running real router software, carrying secrets as type-8 hashes. It is not part of the system; it is the thing the system manages.
• The secrets vault holds the known-good secrets, encrypted at rest, keyed by service and username.
• The verification library generates a hash from a secret, and answers whether a secret and a hash match.
• The verification service exists to answer one question over the network: is this hash the right one for this account? It can also issue a correct replacement hash.
• The assurance engine brings a device back in line: reach it, read its configuration, have each secret verified, correct what fails.
• The syslog receiver turns device configuration events into work. It listens, works out which device changed, and tells the engine.

One cycle, end to end¶

A design is only as good as its ability to describe the workflow it implements. Here is the whole system doing its job once, from the mistyped password change to quiescence:

sequenceDiagram
    autonumber
    actor Operator
    participant Device as Lab device
    participant Receiver as Syslog receiver
    participant Engine as Assurance engine
    participant Service as Verification service

    Operator->>Device: change a secret by hand
    Device->>Receiver: config-change syslog
    Receiver->>Engine: assurance request for the device
    Engine->>Device: fetch running configuration
    Engine->>Service: verify each configured hash
    Service-->>Engine: one hash is wrong
    Engine->>Service: request the correct hash
    Service-->>Engine: fresh type-8 hash
    Engine->>Device: apply corrected configuration
    Device->>Receiver: config-change syslog (the correction itself)
    Receiver->>Engine: assurance request for the device
    Engine->>Service: verify each configured hash
    Service-->>Engine: all hashes correct
    Note over Engine: nothing to change — the cycle ends

Events ten through thirteen are what makes this a system rather than a script. The correction is itself a configuration change, so the device reports it, and the whole cycle runs a second time. That second pass finds everything correct, changes nothing, and therefore provokes nothing. The system comes to rest.

That is not a happy accident, it is a requirement: a design that corrects drift by making changes, in a system triggered by changes, must be able to recognise a corrected device and stop — or it chases its own tail for as long as you leave it running. Everything about how the engine coalesces requests, and why it explicitly reports "nothing to do", is derived from this property.

Decomposition before code¶

Six components, three services. The three that are not services are interesting, because deciding not to make something a service is a decision in itself.

The verification library is a library. It has no state, no I/O, and no lifecycle of its own — give it the same inputs and it returns the same answer forever. Making it a service adds complexity in the form of network I/O — which introduces risk — with no upside. It stays a library for the whole series.

The secrets vault is a store, not a service, and it is owned. Exactly one component may open it.

The network lab is not part of the system at all. It is the external world — and one of the first things this series does is give the external world a stand-in, because you cannot develop a system that rewrites router configurations against routers someone is relying on.

What is worth noticing is that all of this was argued on paper, before a line of code existed, where changes are trivial. The cost of moving a boundary rises steeply once something is built on it — as this series demonstrates.

Data ownership as the first boundary¶

If you take one line from this design, take this one: exactly one component may hold a plaintext secret.

The verification service owns the vault. Nothing else reads it — not by agreement, but because nothing else has any way to. What crosses that boundary is a verdict, or a freshly generated hash. The plaintext does not.

That provides a layer of safety. The assurance engine has enable-level access to every router you own; it logs in, and it rewrites configuration. It is also the component most likely to be running somewhere exposed, doing risky things, at three in the morning. Outside this boundary it can be compromised entirely without leaking a single secret, because it never had one. When it needs to correct a password it asks for a hash of the right value and pushes that.

The alternative — let the engine read the vault, since it is the thing that needs the correct value — works perfectly and is what you would build without drawing this line first. It is also the design where one bug in the riskiest component exposes every credential in the estate.

This is the boundary every later article inherits. It is also the reason the verification library eventually becomes a service: not because of changes in how hashing works, but because something across a process boundary needed to ask a question whose answer must never travel in plaintext.

Where this design was wrong¶

Three things. Two of those were corrected by measuring something, not by thinking harder.

Express. This design named Express as the basis for the verification service — sensible, minimal, what most people reach for. When the service came to be written, the requirement turned out to be one route pair and one JSON body parse, which Node's built-in HTTP server handles in a few lines. Express would have bought familiarity rather than capability, and eliminated a benefit this series maintains through several articles: that a reader installs nothing but the runtime.

nornir. The design chose nornir for the assurance engine's inventory, so that swapping in an external source of truth later would be a one-component change. This added more complexity than it was worth. At implementation, the decision was made to use a dedicated inventory file and call napalm directly, so the declared dependency served no code at all — while napalm, the library the engine's entire safety property rests on, went undeclared and arrived only as nornir's transitive dependency.

The moment of detection. The most critical error. This design names a moment at which a device should report that something changed. That moment is wrong — not subtly, but wrong in a way that undermines the system's entire premise. We will take a closer look at this later in the series.

You may ask why an article introducing a design opens by undermining it. There are two reasons. A design document that admits its own errors before a reader can find them is more credible than one that does not, and you are about to spend nine articles deciding whether to trust this one. And the corrections are not embarrassments to be tidied up, they provide valuable insight about the process.

Here is what the design got right, claimed with the same specificity: the six components and the boundaries drawn between them survived intact. Data ownership never moved. And the cycle above still describes the running system today — every box, every arrow, and the settling behaviour at the end — only a single label changes.

The log and the glossary¶

Two documents did more work than their size suggests, and both are in the download.

The decision log is append-only. Entries are never edited or deleted; when a decision is reversed, a new entry supersedes the old one by name, and both stay. That rule is what makes the Express and nornir reversals visible above rather than invisible — a design document that quietly rewrites itself to match what got built teaches nothing, because the reasoning that was wrong is likely to be repeated.

The glossary holds exactly one term per concept, used verbatim in code and documents. It sounds like paperwork. It is what stops a system growing three names for the same thing across two languages and six components — in a project where "verify" and "assure" refer to genuinely different operations.

How to read this series¶

The nine articles follow the build, each one a runnable milestone. While there is no code yet, you can download the project roadmap along with the decision log and glossary as they stand at this point:

curl -LO https://happypathnetworking.com/assets/releases/quelaag-milestone-0.tar.gz

Subsequent articles will include links to their respective archives.

The reader this is written for is a network engineer getting into programming: the networking is assumed and the software is explained. vrf clab-mgmt needs no explanation; uv run does.

Some articles in the series will run without any hardware or licensed image at all. The rest needs a two-device lab on your laptop, which the next article builds — along with the first script, and an exact demonstration of how not to reboot a virtual router.

One last thing to keep in mind. Nearly every claim in this series was checked against a real device, and several failed the check — including three that produced no error at all, just a confident wrong answer. That is the thread running through all nine articles, and it starts in the next one.

The roadmap as this article describes it, before any code existed: quelaag-milestone-0.tar.gz.
