Reading the $8$¶

The previous article ended with a router handing you two of these and no explanation:

$ uv run scripts/list_users.py r1
Creating virtual environment at: .venv
r1: username admin, secret 8 $8$u3fGmF.bndWAAU$n8ty1Zw8T8fuO49sUj2F/SUGGb18iBpwTycZvCpv8DY
r1: username operator, secret 8 $8$WCiPyXOp22.N7E$gE9z5EgvWcw99VcgWfM9y7FXxM6EBuhhqu6V01rLvGU

If that line is unfamiliar, article 1 builds the lab it came from; the Creating virtual environment line is uv noticing a fresh download and rebuilding its pinned environment, which article 1 also explains.

You already know roughly what you are looking at: the stored form of admin's password, Cisco's type 8, sitting where plaintext must never sit. Here's the question this series is about: Somewhere there is a record of what that password is supposed to be. Given the hashed string and the authoritative record, how do you check that they agree? Answering that continuously, across a fleet, is the whole of Quelaag. Answering it once is this article, and that answer is about fifty lines of JavaScript with no dependencies — plus two facts about the encoding that are difficult to discover.

One addition to the prerequisites, which otherwise have not changed: Node, version 22 or newer — the version this series is built and tested against. The JavaScript in this project has no runtime dependencies and no build step, so installing Node is the whole of it. Grab this article's archive and everything below runs from its root:

curl -LO https://happypathnetworking.com/assets/releases/quelaag-milestone-2.tar.gz
tar -xf quelaag-milestone-2.tar.gz
cd quelaag-milestone-2

What the string says¶

Take admin's line apart. It contains three fields, separated by $:

The scrambling is PBKDF2 with SHA-256: mix the password with the salt, hash it, hash the result, and keep going for 20,000 rounds. Two properties make it fit for the job. It only runs forward — there is no path from the digest back to the password, not with the salt in hand, not with the source code, not with anything. And it is deliberately expensive: 20,000 rounds took about two and a half milliseconds to complete on the author's laptop. No one notices the delay at login while an attacker guessing millions of candidates notices very much. This cost is important because cryptographic hashes are subject to offline brute force attacks. As a consequence, hashing a weak password offers little protection. A truly weak password - say Password1 - is still vulnerable, even when hashed, because it takes very few attempts to crack it.

One-way sounds like a dead end. How do you check a password against something that cannot be reversed? By running the only direction that works: take the password you believe is right, scramble it with the salt stored in the hash — it is sitting right there in the middle field — and compare the result against the digest. Same digest, same password. That re-derive-and-compare move is all verification is, and it is the core of everything this series builds from here.

Why the same password never looks the same¶

Article 1 planted an itch on purpose: admin has the same password on both routers, and the two hashes had nothing in common. Here are both, in two of the four entries of this milestone's test fixtures — real device output, frozen into the download:

{
  "device": "r1",
  "username": "admin",
  "plaintext": "CHANGE-ME-ADMIN",
  "hash": "$8$6MDQWLA4JAG.pU$2NYhnsjdrF.A2jgvUlpYU9DYJvSHgxAND7unfHGB7WY"
},
{
  "device": "r2",
  "username": "admin",
  "plaintext": "CHANGE-ME-ADMIN",
  "hash": "$8$q9UXTeTb16P/M.$p3NFLlH4GzfJzejNAywIiHqPsPsP6AoIlKLm4wpGsf."
}

Same plaintext, entirely different strings — and the salt fields are why. Each device picked its own fourteen characters when it hashed the password, so the digests cannot match. Set the same password twice on one device and the same thing happens.

The fresh salt is deliberate, and a common practice. If identical passwords hashed identically, anyone holding a stolen configuration could see at a glance which accounts share a password — across a fleet, that is a map of what to try first. Worse, they could hash a dictionary of likely passwords once and look every stolen hash up in the result. A salt per password makes both attacks pay full price: the precomputed table is useless, because it was computed with the wrong salts.

The consequence that shapes this whole system: you can never compare two hashes to each other. Does r1 agree with r2, does the device agree with the record — none of these is ever a string comparison. Every check means re-deriving with the salt from the hash in hand. Redeploy the lab and every hash changes; recapture them and the test suite still passes, because the suite never compares hashes — it verifies them.

The library¶

The library in its entirety:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48

import { pbkdf2Sync, randomInt, timingSafeEqual } from "node:crypto";

const ITERATIONS = 20000;
const KEY_LENGTH = 32;
const SALT_LENGTH = 14;

// Cisco encodes with this alphabet rather than standard base64: it starts with
// "./" and has no "+" or "/" at the end. Standard base64 output is translated
// into it character by character.
const CISCO_ALPHABET =
  "./0123456789ABCDEFGHIJKLMNOPQRSTUVWXYZabcdefghijklmnopqrstuvwxyz";
const STANDARD_ALPHABET =
  "ABCDEFGHIJKLMNOPQRSTUVWXYZabcdefghijklmnopqrstuvwxyz0123456789+/";

function toCiscoBase64(bytes) {
  const standard = bytes.toString("base64").replace(/=+$/, "");
  return [...standard]
    .map((character) => CISCO_ALPHABET[STANDARD_ALPHABET.indexOf(character)])
    .join("");
}

function digestFor(plaintext, salt) {
  // The salt's characters are the salt bytes. They are NOT base64-decoded first;
  // decoding produces a valid-looking hash that no device will ever accept.
  const derived = pbkdf2Sync(plaintext, salt, ITERATIONS, KEY_LENGTH, "sha256");
  return toCiscoBase64(derived);
}

export function generateSecret(format, plaintext) {
  const salt = Array.from(
    { length: SALT_LENGTH },
    () => CISCO_ALPHABET[randomInt(CISCO_ALPHABET.length)],
  ).join("");

  return `$8$${salt}$${digestFor(plaintext, salt)}`;
}

export function verifySecret(format, plaintext, hash) {
  const [, , salt, digest] = hash.split("$");
  const candidate = Buffer.from(digestFor(plaintext, salt));
  const stored = Buffer.from(digest);

  // Comparing byte by byte with === would leak, through how long it takes, how
  // much of the digest matched.
  return (
    candidate.length === stored.length && timingSafeEqual(candidate, stored)
  );
}

The import on the first line brings in everything cryptographic that it needs from node:crypto, which ships inside Node. No packages, and no lockfile either — where article 1's Python needed uv to pin netmiko and seventeen packages underneath it, the JavaScript side pins nothing because it installs nothing. It's the same reproducibility argument, in its cheapest possible form.

Two functions are exported, and both take the secret's format as their first argument — which deserves a moment, because the library never looks at the value. That is not an oversight; it is the result of designing for extension without building any of it. Other hash types are on the project's roadmap, and because every caller already names the format it is speaking, adding one later only requires changes to this library. The function call keeps the same interface.

The other line worth a pause is timingSafeEqual. Comparing digests with === stops at the first byte that differs, so how long the comparison takes leaks how much of the digest matched. Today the only caller is you at a terminal, and it will not stay that way — this library is headed behind a network service. The right habit requires one line now.

Watch it answer for the device hash this article opened with:

node --input-type=module -e '
const { verifySecret } = await import("./verification/src/secrets.js");
const hash = "$8$u3fGmF.bndWAAU$n8ty1Zw8T8fuO49sUj2F/SUGGb18iBpwTycZvCpv8DY";
console.log("right plaintext :", verifySecret("type8", "CHANGE-ME-ADMIN", hash));
console.log("wrong plaintext :", verifySecret("type8", "CHANGE-ME-OPERATOR", hash));'

right plaintext : true
wrong plaintext : false

Generation is a two-line command:

// Prints a type-8 hash for the secret given on standard input.
//
// The secret arrives on stdin rather than as an argument because command lines
// are visible to every user on the host through the process table.
//
//   printf 'the-secret' | node verification/src/cli.js

import { generateSecret } from "./secrets.js";

const chunks = [];
for await (const chunk of process.stdin) {
  chunks.push(chunk);
}

console.log(generateSecret("type8", chunks.join("")));

$ printf 'CHANGE-ME-ADMIN' | node verification/src/cli.js     # twice
$8$hzWFbzEJVLhDAi$ZELGtldvjCm6tM0VkQTNwZS8WaxO1tCInSVF/fHPb0M
$8$b/79bvfdN65qKp$BroRH6zPLNjh0SqhjTc04ZP7pMQ5wyGvOcVjkAqLf/k

Two runs with two salts produces two different strings — both verify against CHANGE-ME-ADMIN, and a device would accept either. The stdin method of passing a secret is important, because a command-line argument is visible to every user on the host via the process table; a process's standard input is not.

The test suite runs with one command and no lab:

$ npm test --prefix verification
ok 1 - every device hash verifies against its own plaintext
ok 2 - no device hash verifies against another plaintext
ok 3 - the same secret has different hashes on different devices
ok 4 - a generated hash verifies against the secret it came from
ok 5 - a generated hash looks like the ones devices produce
ok 6 - hashing one secret twenty times gives twenty distinct hashes
# tests 6
# suites 0
# pass 6
# fail 0

node --test is Node's built-in runner; --prefix verification points npm at the right directory. The fixtures are the four captured device hashes, and the suite checks every pairing — each hash against its own plaintext and against every other. Which leaves a fair objection standing: a suite that runs without a lab proves the library agrees with four strings. It cannot prove the library agrees with Cisco.

The two details that are hard to find¶

Type 8 is publicly documented, sort of. The sources agree: PBKDF2 with SHA-256, 20,000 iterations, an 80-bit salt, base64 output. All of that is correct. None of it is sufficient, and the gap hides in two places.

The salt is not decoded. An 80-bit salt encodes to fourteen base64 characters — so when you meet fourteen base64-looking characters in the hash, the reasonable move is to decode them back to ten bytes and hand those to the derivation. The documentation's own correctness baits the mistake: it says 80 bits, and decoding is how you would get 80 bits. Cisco does not decode. The fourteen characters themselves are the salt, passed to PBKDF2 as ASCII text.

The alphabet is not standard base64. Cisco encodes with the crypt-style alphabet that begins ./ and drops +/. Standard base64 output has to be translated across, character by character, and its = padding stripped.

Here is what getting it wrong looks like — the digest of this article's opening hash, computed three ways from the same ingredients:

the device holds           n8ty1Zw8T8fuO49sUj2F/SUGGb18iBpwTycZvCpv8DY

salt used as ASCII text   n8ty1Zw8T8fuO49sUj2F/SUGGb18iBpwTycZvCpv8DY   <- matches the device
salt base64-decoded first aPq.SPnOD.SnZhfdHDp3qYQhdYhcqfcOsiRNrCn93dY   <- plausible, and wrong
standard base64 alphabet  zK5+Dl8KfKr6aGL4gvERBegSSnDKuN18f+ol7O17KPk   <- plausible, and wrong

Nothing about the wrong ones is malformed. Same algorithm, same 20,000 iterations, same salt characters in hand, same length, same character set. An implementation built faithfully from the published parameters produces the second or third line, passes its own tests, verifies its own hashes, round-trips its own generation — and disagrees with every Cisco device on earth, silently, forever. No error is ever raised. The answer is simply incorrect, and the only way to discover that is to hold a digest a real device produced and fail to reproduce it. That is what the stunt-double lab is for, one article after it was built.

This demonstrates the value of developing aginst a real target, rather than a simulated one. Assertion says the implementation is correct. Measurement against a canonical reference says otherwise.

The round trip¶

Reproducing device hashes settles one direction: hashes flowing from the device to the library verify correctly. Generation flows the other way — and a later article will push library-minted hashes onto devices as corrections, so "a device would accept it" cannot be confirmed by a unit test. Only a device gets to say that:

$ uv run scripts/roundtrip_check.py r1
generated $8$3Zqdo2lBpVdAP9$tp8gnmF2xoMZTITYs0WVl3p7/X8f8kppKXLFJ.OaZRA
configured roundtrip on r1
logged in as roundtrip: the device accepts the library's hash
removed roundtrip

The script generates a hash by invoking the Node library as a subprocess from Python — the plaintext crossing on standard input, per the rule — configures it on a throwaway account (roundtrip, in the lab's documented credential table), opens a fresh SSH session authenticating with the original plaintext, and removes the account again.

That Python-asks-JavaScript seam, crossed here by a subprocess, is also a preview. Two articles from now the same question crosses a network instead, and this library gets a service wrapped around it.

Not everything should be a service¶

Which brings up this article's software lesson. A series about microservices has just met its first real component, and the component is not a service. That is deliberate, and worth dwelling on, because the opposite reflex — we are doing services, so the hashing should be a hashing service — is everywhere.

A service gains a process of its own by owning something: state that must live in one place, I/O it must schedule, a lifecycle independent of its callers. This library has none of those. No state — the salt arrives inside the hash, and nothing is remembered between calls. No I/O — its own spec forbids it to touch a device, a vault, or the network; it computes on what it is handed. No lifecycle — it runs exactly when its caller runs. Making it a service anyway incurs a network round trip on every verification, a second process to start, monitor and restart, and a new failure mode — what should a caller conclude when the hashing service is down? — all in exchange for nothing, because every caller everywhere gets the same answer from the same arithmetic.

So it is a library: a function call away from whatever imports it, incapable of being unreachable. And it stays one. When a service does appear in this series, it will not be because hashing requirements changed. It will be because something else needs to ask the question from across a process boundary — and because plaintext secrets must never be allowed to travel back with the answer. The boundary will be earned by data ownership.

What you have now¶

A $8$ string is no longer a blob. Format, salt, digest; why the middle field guarantees you will never see the same string twice; why every check is a fresh derivation and never a comparison. You can verify any device hash against a claimed plaintext in a milliseconds, mint hashes a real router accepts — with the router's own testimony to prove it. And you know the two hidden facts about type 8 hashes.

What you cannot do yet is verify against a known-good password. Verification takes two inputs: the hash off the device, and the plaintext it is supposed to encode. The first is a show running-config away. The second is currently — where, exactly? A password manager? A spreadsheet? Someone's memory? For a system that intends to verify secrets continuously, the known-good plaintext has to live somewhere a program can reach. That somewhere is the next article.

The library exactly as this article describes it: quelaag-milestone-2.tar.gz.
